Introducing, Ampel Inc. was established in 1983
As a quick turn prototype shop servicing the Chicago area electronic manufacturing companies printed circuit needs with a commitment to quality, reliable service and customer satisfaction.
We now service customers nationwide offering rapid prototyping service through production deliverers of all types of Printed Circuit Boards.
We are pleased to announce that Ampel Inc, has acquired Image Circuit Inc. of Elgin IL. Ampel Inc, is a market-leading PCB manufacturer and this acquisition positions our company to attain additional customers, staff, experience and expand capability limits. This is an exciting time for our team, customers base and we're ecstatic to share this news. we will remain focused on our customers and strengthen and build on our promise to deliver even greater value. Meet us at the top!
Aluminum Based PCBs
are a unique metal-based copper clad laminate. These types of Printed Circuit Boards have good thermal conductivity, electrical insulation and very solid machining performance.
0.138” Thickness, 6 oz copper thickness.
Top side LPI mask, bottom side Polyimide martial
Upto 3 to 6 mil thickness.
Immersion Gold (ENIG)
Electroless Nickel Immersion Gold is one of the most popular widely-used circuit board finishes available today. Constructed with two layers of coating, ENIG places 2-4 μ” Au over 120-200 μ” Ni.
12 layer, 5/5 mil, 6 mil drill, edge planting.
Rigid and Flex
Another rigid PCB product option provided by Ampel is the 4 layer polyimide PCB. Polyimide is chosen as the material for the inner layers as it comprises good mechanical properties, high chemical resistance, and thermal stability.
4 Layer Rigid and Flex
No matter if your PCB is Flex or Rigid Flex, AMPEL Inc. has the equipment and expertise to handle any combination or configuration.
2 Layer, 4.7 mil Thickness.
Immersion Tin (IAg) is applied directly to the base metal of a PCB via chemical displacement. It’s a more affordable option than ENIG, and it is also RoHS-compliant. A typical thickness for Immersion Silver is 4-12u”.
6 layer, 6 oz with special chemferts.
VIPPO is rapidly becoming more commonly used in modern printed circuit design due to the ever decreasing pitch of component footprints, along with the need to miniaturize PCB form factor.
Via in pad and plated over (VIPPO)
One of the newest developments materials is flexible dielectrics. These materials feature a polyimide resin system with ceramic fillers which provides excellent electrical insulation, flexibility and of course thermal conductivity.
2 Layer, white and black mask
Why Choose Us
- PLANT SIZE: 35,200 sq. ft.
- DATE ESTABLISHED: 1983
- 24 hours on 1 to 6 layer
- 48 hours on 8 to 10 layers
- 72 hours on 12 to 14 layers
- Above 14 layers call us
BOARD TYPES AVAILABLE:
- Single and Double sided
- Multilayers through 14 layers
- Flex and rigid flex
- Teflon, Duriod and Getek
- Aluminium Led Boards
SPECIFICATIONS AND TESTING:
- We are UL 94V-0 approved and build to IPC-A-600 Standards
- Electrical Testing - Flying Grid, single sided Clam Shell and Net List testing
- Cross Section analysis
- Ionic Contamination
Ampel Inc. is a full service PCB manufacturer providing leading edge printed circuit board technology and innovative, profitable value-added services.With extensive experience and ISO certification, we offer a complete menu of PCB capabilities, including stock and custom work.Our headquarters is located in a modern 35,000 sq. ft. manufacturing facility, located in Elk Grove Village, Illinois near Chicago's O'Hare International Airport.
"Customer happy with our great service and our ability to expedite order more often than not." -
"Customer enjoy are competitive pricing. has been giving us more work." -
"Customer is glad that we keep stock on hand in case they have shortages." -
"Able to ship out boards earlier than expected, customer is glad." -
"Customer happy with our quick quote response." -
Ampel Inc. was established in 1983 as a quick turn prototype shop servicing the Chicago area electronic manufacturing companies printed circuit needs with a commitment to quality, reliable service and customer satisfaction.
